Description
The Stage1 ST180 Eco Boost intercooler features our proven race quality Bar ‘n’ Plate core, this core has always proved to out perform its lighter weight Tube and Fin competitor. The new ST Fiesta is a great car and why not make it even better and fit the best, fit AIRTEC.
Fast Ford magazine intercooler test – measured in degrees C
Standard
Run 1 Intake temp turbo into intercooler 140 out of intercooler into engine 85
Run 2 Intake temp turbo into intercooler 131 out of intercooler into engine 92
Run 3 Intake temp turbo into intercooler 140 out of intercooler into engine 97
AIRTEC
Run 1 Intake temp turbo into intercooler 140 out of intercooler into engine 31
Run 2 Intake temp turbo into intercooler 150 out of intercooler into engine 38
Run 3 Intake temp turbo into intercooler 152 out of intercooler into engine 39
Dimensions
OEM Intercooler
Width: 690mm
Height: 130mm
Depth: 50mm
Capacity: 4.5 litres
Front area: 900cm²
AIRTEC Motorsport Intercooler
Width: 710mm
Height: 150mm
Depth: 70mm
Capacity: 7.5 litres
Front area: 1,070cm²
Features:
1 x huge 70mm core Intercooler with flowed cast end tanks, this means less welding and a stronger Intercooler (Ford Intercooler 50mm core)
Come with full fitting instructions
No cutting or drilling with this kit
Logos have been put onto flowed cast end tanks
Un-Beatable value for money
Proven Power Increase’s for Fast Road & Track
Available in Satin Black or Natural Silver
AIRTEC 3-year unlimited mileage warranty
Fitting will take 1-2 hours depending on mechanical skill
Proven to handle 250bhp
Highly efficient core capable of dealing with power levels from standard up to stage 2 software time and time again, perfect for your fast road car. To read a more in depth investigation into this intercoolers performance on our track time Fiesta Click Here.
Will fit Fiesta ST 200
Approximate dimensions:
Height – 150mm
Core thickness – 70mm
Overall width – 1000mm (Including end pipes)
63mm pipe outlets
Registered Design Right number: 6023241
AIRTEC part number: ATINTFO25
